25.6V 120AH,51.2V 60AH MS Series Lithium Battery
| PRODUCT SPECIFICATION | ||
| Technical data | ||
| Model | MS24120 | MS4860 |
| Nominal Voltage | 25.6V | 51.2V |
| Nominal Capacity | 120Ah | 60Ah |
| Stored Energy | 3.07kwh | 3.07kwh |
| Self discharge(per month) | max3% | max3% |
| Cycle Life | ＞3,500times | ＞3,500times |
| Charge Current | 50A | 50A |
| Discharge Current | 100A | 100A |
| Maximun Discharge | 400A（4S） | 400A（4S） |
| Standard Charge | 2.4h | 1.2h |
| Charge Temperature | （0℃~55℃） | （0℃~55℃） |
| Discharge Temperature | （-20℃~55℃） | （-20℃~55℃） |
| Storage Temperature(1month) | （-20℃~45℃） | （-20℃~45℃） |
| Storage Temperature(1year) | （0℃~35℃） | （0℃~35℃） |
| Cell Combination | 8S4P | 16S2P |
| IP Rating | IP65 | IP65 |
| Cell Assembly | LFP（3.2V30Ah） | LFP（3.2V30Ah） |
| Casing Material | Steel | Steel |
| Heat | Optional | Optional |
| Control Panel | Optional | Optional |
| Dimension(L*W*h)mm | 350*270*210mm | 350*270*210mm |
| Dimension(L*W*h)inch | 13.8*10.6*8.3inch | 13.8*10.6*8.3inch |
| Net Weight(kg) | 26.5kg | 26.5kg |
| Net Weight(lbs) | 58.3Ibs | 58.3Ibs |
Applicable for :
• Golf Cart
• Motor Home
• Ariel Platform
• Cleaning Equipment
• Portable Energy Storage
• Golf Cart
• Motor Home
• Ariel Platform
• Cleaning Equipment
• Portable Energy Storage
